feat(emotion,ui-scripts): resolve tokens studio color modifiers and emit hex

[HerrTopi]

Forward Tokens Studio color modifiers ($extensions.studio.tokens.modify) through the theme build scripts and resolve them at theme-apply time so semantic and component tokens can chain darken/lighten/alpha.

• generateSemantics: emit the { value, modify } payload for semantic tokens and recurse into it in resolveReferences (drop the .value/.type guard that serialized the payload to "[object Object]").
• generateComponents: only forward $extensions when studio.tokens.modify is present, so tokens carrying unrelated metadata no longer emit modify: undefined.
• applyColorModifiers: serialize the resolved color to hex (#RRGGBBAA when alpha < 1, #RRGGBB otherwise) so modifier-derived values match every other token.
• useComputedTheme/useStyleNew/withStyleNew: resolve modifiers on semantics before building component and shared tokens, so component-level modifiers chain on top of already-resolved semantic values; key component overrides by the component's own id rather than the token-source id.
• Bump @instructure/instructure-design-tokens to v1.4.0.

🤖 Generated with Claude Code

[github-actions]

PR Preview Action v1.8.1
🚀 View preview at https://instructure.design/pr-preview/pr-2626/
Built to branch gh-pages at 2026-07-09 15:17 UTC. Preview will be ready when the GitHub Pages deployment is complete.

[github-actions]

Visual regression report

⚠️ Changes detected.

Status	Count
Unchanged	31
Changed	1
New	0
Removed	0

📊 View full report

Diff images (1)

button-and-derivatives.png — 440 pixels differ

_{Baselines come from the visual-baselines branch. They refresh on every merge to master.}

[ToMESSKa]

This type of override does not not work unless you change both keys (Button and IconButton) to BaseButton, but that results in not being able to override the two components separately.

<InstUISettingsProvider
    themeOverride={{
      components: {
        Button: { primaryBackground: 'red', smallPaddingTop: '1px' },
        IconButton: { primaryBackground: 'blue', secondaryBackground: 'green' }
      }
    }}

  >
    <Button color="primary">x</Button>
  <IconButton color="primary">x</IconButton>
  </InstUISettingsProvider>

[ToMESSKa]

Also a similar example, this only works if both key is TreeBrowserTreeButton.

const renderNode = () => (
  <TreeBrowser.Node itemIcon={<IconPlusLine />}>More</TreeBrowser.Node>
)

const Example = () => (
  <InstUISettingsProvider
    themeOverride={{
      components: {
        'TreeBrowser.Button': { hoverBackgroundColor: 'red' },
        'TreeBrowser.Node': { hoverBackgroundColor: 'blue' }
      }
    }}
  >
    <TreeBrowser
      rootId={1}
      defaultExpanded={[1]}
      collections={{
        1: {
          id: 1,
          name: 'Assignments',
          collections: [],
          items: [1, 2],
          renderAfterItems: renderNode()
        }
      }}
      items={{
        1: { id: 1, name: 'Addition Worksheet' },
        2: { id: 2, name: 'Subtraction Worksheet' }
      }}
    />
  </InstUISettingsProvider>
)

render(<Example />)

Also in some cases the component key used in the InstUISettingsProvider changed:

v1 key	v2 key
TreeBrowser.Collection	TreeBrowserTreeCollection
ColorMixer.Palette	Palette
ColorMixer.Slider	Slider
ColorMixer.RGBAInput	RgbaInput
TopNavBar.DesktopLayout	TopNavBarLayout
TopNavBar.SmallViewportLayout	TopNavBarLayout

For example here only the Palette key can be used instead of ColorMixer.Palette (v1). The question is: should my codemod I'm working on handle these key changes or should we change something in the InstUI code?

const Example = () => {
     const [value, setValue] = useState('#328826')

     return (
       <InstUISettingsProvider
         themeOverride={{
           components: {
             'Palette': {
               paletteBorderRadius: '1rem',
               paletteBorderWidth: '0.25rem'
             }
           }
         }}
       >
         <ColorMixer
           value={value}
           onChange={(value) => setValue(value)}
           rgbRedInputScreenReaderLabel="Input field for red"
           rgbGreenInputScreenReaderLabel="Input field for green"
           rgbBlueInputScreenReaderLabel="Input field for blue"
           rgbAlphaInputScreenReaderLabel="Input field for alpha"
           colorSliderNavigationExplanationScreenReaderLabel="Use arrow keys to adjust hue"
           alphaSliderNavigationExplanationScreenReaderLabel="Use arrow keys to adjust alpha"
           colorPaletteNavigationExplanationScreenReaderLabel="Use arrow keys to move the picker"
         />
       </InstUISettingsProvider>
     )
   }

   render(<Example />)
